Industrial Automation

Industrial Automation

Discontinued On Mar. 2023

E2EM

Long-distance Proximity Sensor

E2EM

Long-distance Proximity Sensor

* Information in this page is a reference that you created on the basis of information in the product catalog before the end of production, may be different from the current situation, such as goods for / supported standards options / price / features of the product. Before using, please check the compatibility and safety system.

(Unit: mm)

Tolerance class IT16 applies to dimensions in this data sheet unless otherwise specified.

Pre-wired Models (Shielded)

E2EM Dimensions 2

E2EM-X2C[]

E2EM Dimensions 3

E2EM-X4[][]

E2EM Dimensions 4

E2EM-X8[][]

E2EM Dimensions 5

E2EM-X15[][]

E2EM Dimensions 6

Pre-wired Models (Unshielded)

E2EM-X16MX[]

E2EM Dimensions 8

E2EM-X30MX[]

E2EM Dimensions 9

Connector Models (Shielded )

E2EM Dimensions 11

E2EM-X2C[]-M1

E2EM Dimensions 12

E2EM-X4C[]-M1

E2EM Dimensions 13

E2EM-X8C[]-M1

E2EM Dimensions 14

E2EM-X15C[]-M1

E2EM Dimensions 15
