Industrial Automation

E3F3

Photoelectric Sensor

E3F3

Threaded Cylindrical Photoelectric Sensor with Built-in Amplifier for Use as an Optical Proximity Sensor High Noise-immunity with Photo-IC Technology

last update: January 22, 2014

(Unit: mm)

Note: All units are in millimeters unless otherwise indicated.

Sensors

	Plastic housing	Metal housing
Pre-wired	E3F3-D[]2	E3F3-D[]2M
M12 connector	E3F3-D[]7	E3F3-D[]7M
Pre-wired	E3F3-T[]1 E3F3-R[]1 E3F3-R[]2 E3F3-D[]1	E3F3-T[]1M E3F3-R[]1M E3F3-R[]2M E3F3-D[]1M
M12 connector	E3F3-T[]6 E3F3-R[]6 E3F3-R[]7 E3F3-D[]6	E3F3-T[]6M E3F3-R[]6M E3F3-R[]7M E3F3-D[]6M

Note:Pre-wired Cord: Polyvinyl chloride-covered cord, 4-mm dia. (18/0.12),
                              Standard length: 2 m
                              Emitter: 2-conductor (brown and blue)
                              Receiver and Reflective model: 3-conductor (brown, blue, and black)
M12 connector: 3214_dm_1_9 1: +V, 2: NC, 3: 0 V, 4: Output
